Description
Irrespective of whether pumping, ventilating, compressing, moving or processing: SINAMICS G120 is the universal drive to address the widest range of requirements. It leverages its strengths in general machinery construction as well as in the automotive, textile and packaging industries. Its modular design and wide range of power ratings extending from 0.55 kW up to 250 kW always ensures that you can configure the optimum inverter for your particular application.
- Comprehensive range of encoder interfaces
- Application-oriented control modules with expanded I/O quantity scope
- Positioning capability (EPos)
- Safety Integrated: STO, SS1, SBC, SLS, SDI, SSM
- Power Modules with low line harmonics
- Energy recovery into the line supply without requiring additional modules
- Integral part of Totally Integrated Automation. Automation – with interfaces for PROFINET and PROFIBUS
- Profiles that are supported: PROFIdrive, PROFIsafe, PROFIenergy
- Coupling to third-party systems via USS / Modbus RTU, CANopen, BacNet MS / TP, EtherNet/ IP
| Manufacturer: | Siemens |
| Series: | SINAMICS G120 |
| Model: | 6SL3210-1PB21-4UL0 |
| Application: | general purpose |
| Capacity, kW: | 3 |
| Current, А: | 13.6 |
| Main power supply, V: | 200-240 |
| Phase: | 1/3 |
| Output frequency, Hz: | 0-650 (V/f), 0-200 (vector) |
| Enclosure: | IP 20 |
| Overload capacity, % per 1 min.: | 150 (LO), 200 (HO) |
| Acceleration time, sec: | 0-650 |
| Deceleration time, sec: | 0-650 |
| EMC filter: | - |
| Braking unit: | + |
| Analog input: | 1-2 |
| Digital input: | 4-11 |
| Analog output: | 1-2 |
| Digital output: | 1-7 |
| Relay output: | 2 |
| RS485 (Modbus RTU): | USS/Modbus RTU, PROFIBUS DP,PROFINET |
| PID: | PID - controller |
| V/f control mode: | + |
| Vector control with feedback: | + |
| Sensorless vector control: | + |
| Operation temperature, °С: | -10......+40 |
| Storage temperature, °С: | -40......+70 |
| Dimensions (W x H x D), mm: | 189x334x185 |
