195B0345 Danfoss Reciprocating compressor, SC10MLX

Write a Review
SKU:
195B0345
Availability:
2 - 3 weeks

Product details Gross weight 13.81 kg Net weight 13.81 kg EAN 5702428583473 Gross weight 13.81 kg Net weight 13.8…

Adding to cart… The item has been added
Ask for a Quotation

Ask for a Quotation

Feel free to inquire
Request a Quote
  • Security Image 1
Description

Product details

Gross weight 13.81 kg
Net weight 13.81 kg
EAN 5702428583473
Gross weight 13.81 kg
Net weight 13.81 kg
EAN 5702428583473



Application energy level Standard MBP
Applications MBP
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] 14.5 Ohm
Base plate type Universal
Brand technique Reciprocating compressor
Capacity control Fixed speed
Colour Black
Compressor power supply [V/Ph/Hz] 220/1/50 220/1/60
Configuration code Single
Cut in current HST [A] 19.5 A
Description SC10MLX
Discharge connection angle [°] 37 °
Discharge connection comments Rubber plug
Discharge connection diameter [mm] 6.5 mm
Discharge connection height [mm] 100 mm
Discharge connection material Copper
Economizer No
Free gas volume [cm3] 1410 cm3
Frequency [Hz] 50/60
Height from baseplate [mm] 203 mm
High value of nominal voltage at 50Hz [V] 240 V
High value of nominal voltage at 60Hz [V] 240 V
High value of voltage range at 50Hz [V] 255 V
High value of voltage range at 60Hz [V] 255 V
Length [mm] 255 mm
Liquid injection No
Low value of nominal voltage at 50Hz [V] 220 V
Low value of nominal voltage at 60Hz [V] 220 V
Low value of voltage range at 50Hz [V] 187 V
Low value of voltage range at 60Hz [V] 187 V
LRA HST 60Hz [A] 19.5 A
LRA HST [A] 19.5 A
Main winding resistance for single-phase compressors [Ohm] 4.4 Ohm
Model number SC10MLX
Motor type CSIR
No. of phases (compressor) 1
Oil quantity [cm3] 600 cm3
Oil type POE
Packing format Industrial pack
Packing quantity 80
Phase 1
Process connection angle [°] 37 °
Process connection comments Rubber plug
Process connection diameter [mm] 6.5 mm
Process connection height [mm] 183 mm
Process connection material Copper
Refrigerant R404A
R507
Refrigerant charge [kg] [Max] 1.3 kg
RLA 3.90 A
Rotational speed at 50Hz [rpm] 3000 rpm
Rotational speed at 60Hz [rpm] 3600 rpm
Segment usage Refrigeration MT
Start capacitor capacitance 80 µF
Suction connection angle [°] 37 °
Suction connection comments Rubber plug
Suction connection diameter [mm] 8.2 mm
Suction connection height [mm] 183 mm
Suction connection material Copper
Swept volume [cm3] 10.29 cm3
Technology Reciprocating
Total height [mm] 209 mm
Type SC
Type designation Compressor
Voltage 50Hz [V] 220 V
Voltage 50Hz [V] [Max] 240 V
Voltage 60Hz [V] 208 V
Voltage 60Hz [V] [Max] 230 V
Width [mm] 151 mm
Application energy level Standard MBP
Applications MBP
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] 14.5 Ohm
Base plate type Universal
Brand technique Reciprocating compressor
Capacity control Fixed speed
Colour Black
Compressor power supply [V/Ph/Hz] 220/1/50 220/1/60
Configuration code Single
Cut in current HST [A] 19.5 A
Description SC10MLX
Discharge connection angle [°] 37 °
Discharge connection comments Rubber plug
Discharge connection diameter [mm] 6.5 mm
Discharge connection height [mm] 100 mm
Discharge connection material Copper
Economizer No
Free gas volume [cm3] 1410 cm3
Frequency [Hz] 50/60
Height from baseplate [mm] 203 mm
High value of nominal voltage at 50Hz [V] 240 V
High value of nominal voltage at 60Hz [V] 240 V
High value of voltage range at 50Hz [V] 255 V
High value of voltage range at 60Hz [V] 255 V
Length [mm] 255 mm
Liquid injection No
Low value of nominal voltage at 50Hz [V] 220 V
Low value of nominal voltage at 60Hz [V] 220 V
Low value of voltage range at 50Hz [V] 187 V
Low value of voltage range at 60Hz [V] 187 V
LRA HST 60Hz [A] 19.5 A
LRA HST [A] 19.5 A
Main winding resistance for single-phase compressors [Ohm] 4.4 Ohm
Model number SC10MLX
Motor type CSIR
No. of phases (compressor) 1
Oil quantity [cm3] 600 cm3
Oil type POE
Packing format Industrial pack
Packing quantity 80
Phase 1
Process connection angle [°] 37 °
Process connection comments Rubber plug
Process connection diameter [mm] 6.5 mm
Process connection height [mm] 183 mm
Process connection material Copper
Refrigerant R404A
R507
Refrigerant charge [kg] [Max] 1.3 kg
RLA 3.90 A
Rotational speed at 50Hz [rpm] 3000 rpm
Rotational speed at 60Hz [rpm] 3600 rpm
Segment usage Refrigeration MT
Start capacitor capacitance 80 µF
Suction connection angle [°] 37 °
Suction connection comments Rubber plug
Suction connection diameter [mm] 8.2 mm
Suction connection height [mm] 183 mm
Suction connection material Copper
Swept volume [cm3] 10.29 cm3
Technology Reciprocating
Total height [mm] 209 mm
Type SC
Type designation Compressor
Voltage 50Hz [V] 220 V
Voltage 50Hz [V] [Max] 240 V
Voltage 60Hz [V] 208 V
Voltage 60Hz [V] [Max] 230 V
Width [mm] 151 mm
Refrigerant: R404A; R507, Segment usage: Refrigeration MT, Compressor power supply [V/Ph/Hz]: 220/1/50 220/1/60
