180L0127 Danfoss Valve, VDHT 3/8 E HP

Write a Review
SKU:
180L0127
Availability:
2 - 3 weeks

Product details Gross weight 1.15 kg Net weight 1.15 kg Gross weight 1.15 kg Net weight 1.15 kg   Actua…

Adding to cart… The item has been added
Ask for a Quotation

Ask for a Quotation

Feel free to inquire
Request a Quote
  • Security Image 1
Description

Product details

Gross weight 1.15 kg
Net weight 1.15 kg
Gross weight 1.15 kg
Net weight 1.15 kg



Actuator size [mm] 13.5 mm
Body material AISI 304
Closing Time [ms] [Max] 300 ms
Closing Time [ms] [Min] 200 ms
Connection standard NPT
Connection type Thread
Direction Straightway
Flow [gpm] [Max] 8 gal/min
Flow [gpm] [Min] 0 gal/min
Flow [l/min] [Max] 30 L/min
Flow [l/min] [Min] 0 L/min
Function NC
Inlet connection size [in] 3/8 in
Material type Neutral media
Media temperature [°C] [Max] 90 °C
Media temperature [°C] [Min] 2 °C
Media temperature [°F] [Max] 194 °F
Media temperature [°F] [Min] 36 °F
Number of ways 2/2
Opening time [ms] [Max] 125 ms
Opening time [ms] [Min] 100 ms
Operating pressure [barg] [Max] 210 barg
Operating pressure [barg] [Min] 4 barg
Operating pressure [psig] [Max] 3000 psig
Operating pressure [psig] [Min] 51 psig
Operation Pilot operated
Outlet connection size [in] 3/8 in
Parts Program name VDHT
Piston diameter Ø [mm] 18 mm
Product group Valve
Product name Solenoid operated valves
Seal Material FKM
Serviceable Yes
Type VDHT 2/2
Type designation VDHT 3/8 E HP
Actuator size [mm] 13.5 mm
Body material AISI 304
Closing Time [ms] [Max] 300 ms
Closing Time [ms] [Min] 200 ms
Connection standard NPT
Connection type Thread
Direction Straightway
Flow [gpm] [Max] 8 gal/min
Flow [gpm] [Min] 0 gal/min
Flow [l/min] [Max] 30 L/min
Flow [l/min] [Min] 0 L/min
Function NC
Inlet connection size [in] 3/8 in
Material type Neutral media
Media temperature [°C] [Max] 90 °C
Media temperature [°C] [Min] 2 °C
Media temperature [°F] [Max] 194 °F
Media temperature [°F] [Min] 36 °F
Number of ways 2/2
Opening time [ms] [Max] 125 ms
Opening time [ms] [Min] 100 ms
Operating pressure [barg] [Max] 210 barg
Operating pressure [barg] [Min] 4 barg
Operating pressure [psig] [Max] 3000 psig
Operating pressure [psig] [Min] 51 psig
Operation Pilot operated
Outlet connection size [in] 3/8 in
Parts Program name VDHT
Piston diameter Ø [mm] 18 mm
Product group Valve
Product name Solenoid operated valves
Seal Material FKM
Serviceable Yes
Type VDHT 2/2
Type designation VDHT 3/8 E HP
Type: VDHT, Connection standard: NPT, Flow [gpm] [Max]: 8.000, Function: NC, Operation: Pilot operated, Direction: Straightway
