Description
Flow [gpm] [Max]: 21.780, Flow [l/min] [Max]: 83.760, Outlet pressure [barg] [Max]: 80, Speed [rpm] [Max]: 1800, Speed [rpm] [Min]: 700, ATEX compliance: Ex II 2G cb T6 / Ex II 3G c T6, Body material: Duplex
Product details
| Gross weight | 36 kg |
| Net weight | 28.84 kg |
| Gross weight | 36 kg |
| Net weight | 28.84 kg |
| Ambient temperature [°C] [Max] | 50 °C |
| Ambient temperature [°C] [Min] | 0 °C |
| Ambient temperature [°F] [Max] | 122 °F |
| Ambient temperature [°F] [Min] | 32 °F |
| ATEX compliance | Ex II 2G cb T6 / Ex II 3G c T6 |
| Body material | Duplex |
| Country of origin | Denmark |
| Displacement [cm³/rev] | 50.2 cm3/rev |
| Displacement [in³/rev] | 3.06 in3/rev |
| Drain connection size (metric) | M6 |
| Drain connection standard | Metric |
| Drain connection type | Thread |
| Flow [gpm] [Max] | 21.78 gal/min |
| Flow [gpm] [Min] | 7.42 gal/min |
| Flow [l/min] [Max] | 83.76 L/min |
| Flow [l/min] [Min] | 28.54 L/min |
| Flow [m³/h] [Max] | 5.03 m3/h |
| Flow [m³/h] [Min] | 1.71 m3/h |
| Inlet connection size (metric) | M42 |
| Inlet connection standard | Metric |
| Inlet connection type | Thread |
| Inlet pressure [barg] [Max] | 5 barg |
| Inlet pressure [barg] [Min] | 0.5 barg |
| Inlet pressure [psig] [Max] | 72.5 psig |
| Inlet pressure [psig] [Min] | 7.3 psig |
| Inlet pressure peak [barg] [Max] | 5 barg |
| Inlet pressure peak [psig] [Max] | 73 psig |
| Media temperature [°C] [Max] | 50 °C |
| Media temperature [°C] [Min] | 2 °C |
| Media temperature [°F] [Max] | 122 °F |
| Media temperature [°F] [Min] | 36 °F |
| Outlet connection size (metric) | M42 |
| Outlet connection standard | Metric |
| Outlet connection type | Thread |
| Outlet pressure [barg] [Max] | 80 barg |
| Outlet pressure [barg] [Min] | 20 barg |
| Outlet pressure [psig] [Max] | 1160 psig |
| Outlet pressure [psig] [Min] | 290 psig |
| Outside dimensions of packaging LxWxH [in] | 14,9x11,8x11,8 |
| Outside dimensions of packaging LxWxH [mm] | 380x300x300 |
| Product group | Pump |
| Product name | APP pumps |
| Seal Material | NBR |
| Serviceable | Yes |
| Sound pressure level [dB(A)] | 78 dBA |
| Speed continuous[rpm] [Min] | 700 rpm |
| Speed [rpm] [Max] | 1800 rpm |
| Speed [rpm] [Min] | 700 rpm |
| Type | APP 5.1-10.2 |
| Type designation | APP 5.1 Ex |
| Ambient temperature [°C] [Max] | 50 °C |
| Ambient temperature [°C] [Min] | 0 °C |
| Ambient temperature [°F] [Max] | 122 °F |
| Ambient temperature [°F] [Min] | 32 °F |
| ATEX compliance | Ex II 2G cb T6 / Ex II 3G c T6 |
| Body material | Duplex |
| Country of origin | Denmark |
| Displacement [cm³/rev] | 50.2 cm3/rev |
| Displacement [in³/rev] | 3.06 in3/rev |
| Drain connection size (metric) | M6 |
| Drain connection standard | Metric |
| Drain connection type | Thread |
| Flow [gpm] [Max] | 21.78 gal/min |
| Flow [gpm] [Min] | 7.42 gal/min |
| Flow [l/min] [Max] | 83.76 L/min |
| Flow [l/min] [Min] | 28.54 L/min |
| Flow [m³/h] [Max] | 5.03 m3/h |
| Flow [m³/h] [Min] | 1.71 m3/h |
| Inlet connection size (metric) | M42 |
| Inlet connection standard | Metric |
| Inlet connection type | Thread |
| Inlet pressure [barg] [Max] | 5 barg |
| Inlet pressure [barg] [Min] | 0.5 barg |
| Inlet pressure [psig] [Max] | 72.5 psig |
| Inlet pressure [psig] [Min] | 7.3 psig |
| Inlet pressure peak [barg] [Max] | 5 barg |
| Inlet pressure peak [psig] [Max] | 73 psig |
| Media temperature [°C] [Max] | 50 °C |
| Media temperature [°C] [Min] | 2 °C |
| Media temperature [°F] [Max] | 122 °F |
| Media temperature [°F] [Min] | 36 °F |
| Outlet connection size (metric) | M42 |
| Outlet connection standard | Metric |
| Outlet connection type | Thread |
| Outlet pressure [barg] [Max] | 80 barg |
| Outlet pressure [barg] [Min] | 20 barg |
| Outlet pressure [psig] [Max] | 1160 psig |
| Outlet pressure [psig] [Min] | 290 psig |
| Outside dimensions of packaging LxWxH [in] | 14,9x11,8x11,8 |
| Outside dimensions of packaging LxWxH [mm] | 380x300x300 |
| Product group | Pump |
| Product name | APP pumps |
| Seal Material | NBR |
| Serviceable | Yes |
| Sound pressure level [dB(A)] | 78 dBA |
| Speed continuous[rpm] [Min] | 700 rpm |
| Speed [rpm] [Max] | 1800 rpm |
| Speed [rpm] [Min] | 700 rpm |
| Type | APP 5.1-10.2 |
| Type designation | APP 5.1 Ex |
Product details
| Gross weight | 36 kg |
| Net weight | 28.84 kg |
| Gross weight | 36 kg |
| Net weight | 28.84 kg |
| Ambient temperature [°C] [Max] | 50 °C |
| Ambient temperature [°C] [Min] | 0 °C |
| Ambient temperature [°F] [Max] | 122 °F |
| Ambient temperature [°F] [Min] | 32 °F |
| ATEX compliance | Ex II 2G cb T6 / Ex II 3G c T6 |
| Body material | Duplex |
| Country of origin | Denmark |
| Displacement [cm³/rev] | 50.2 cm3/rev |
| Displacement [in³/rev] | 3.06 in3/rev |
| Drain connection size (metric) | M6 |
| Drain connection standard | Metric |
| Drain connection type | Thread |
| Flow [gpm] [Max] | 21.78 gal/min |
| Flow [gpm] [Min] | 7.42 gal/min |
| Flow [l/min] [Max] | 83.76 L/min |
| Flow [l/min] [Min] | 28.54 L/min |
| Flow [m³/h] [Max] | 5.03 m3/h |
| Flow [m³/h] [Min] | 1.71 m3/h |
| Inlet connection size (metric) | M42 |
| Inlet connection standard | Metric |
| Inlet connection type | Thread |
| Inlet pressure [barg] [Max] | 5 barg |
| Inlet pressure [barg] [Min] | 0.5 barg |
| Inlet pressure [psig] [Max] | 72.5 psig |
| Inlet pressure [psig] [Min] | 7.3 psig |
| Inlet pressure peak [barg] [Max] | 5 barg |
| Inlet pressure peak [psig] [Max] | 73 psig |
| Media temperature [°C] [Max] | 50 °C |
| Media temperature [°C] [Min] | 2 °C |
| Media temperature [°F] [Max] | 122 °F |
| Media temperature [°F] [Min] | 36 °F |
| Outlet connection size (metric) | M42 |
| Outlet connection standard | Metric |
| Outlet connection type | Thread |
| Outlet pressure [barg] [Max] | 80 barg |
| Outlet pressure [barg] [Min] | 20 barg |
| Outlet pressure [psig] [Max] | 1160 psig |
| Outlet pressure [psig] [Min] | 290 psig |
| Outside dimensions of packaging LxWxH [in] | 14,9x11,8x11,8 |
| Outside dimensions of packaging LxWxH [mm] | 380x300x300 |
| Product group | Pump |
| Product name | APP pumps |
| Seal Material | NBR |
| Serviceable | Yes |
| Sound pressure level [dB(A)] | 78 dBA |
| Speed continuous[rpm] [Min] | 700 rpm |
| Speed [rpm] [Max] | 1800 rpm |
| Speed [rpm] [Min] | 700 rpm |
| Type | APP 5.1-10.2 |
| Type designation | APP 5.1 Ex |
| Ambient temperature [°C] [Max] | 50 °C |
| Ambient temperature [°C] [Min] | 0 °C |
| Ambient temperature [°F] [Max] | 122 °F |
| Ambient temperature [°F] [Min] | 32 °F |
| ATEX compliance | Ex II 2G cb T6 / Ex II 3G c T6 |
| Body material | Duplex |
| Country of origin | Denmark |
| Displacement [cm³/rev] | 50.2 cm3/rev |
| Displacement [in³/rev] | 3.06 in3/rev |
| Drain connection size (metric) | M6 |
| Drain connection standard | Metric |
| Drain connection type | Thread |
| Flow [gpm] [Max] | 21.78 gal/min |
| Flow [gpm] [Min] | 7.42 gal/min |
| Flow [l/min] [Max] | 83.76 L/min |
| Flow [l/min] [Min] | 28.54 L/min |
| Flow [m³/h] [Max] | 5.03 m3/h |
| Flow [m³/h] [Min] | 1.71 m3/h |
| Inlet connection size (metric) | M42 |
| Inlet connection standard | Metric |
| Inlet connection type | Thread |
| Inlet pressure [barg] [Max] | 5 barg |
| Inlet pressure [barg] [Min] | 0.5 barg |
| Inlet pressure [psig] [Max] | 72.5 psig |
| Inlet pressure [psig] [Min] | 7.3 psig |
| Inlet pressure peak [barg] [Max] | 5 barg |
| Inlet pressure peak [psig] [Max] | 73 psig |
| Media temperature [°C] [Max] | 50 °C |
| Media temperature [°C] [Min] | 2 °C |
| Media temperature [°F] [Max] | 122 °F |
| Media temperature [°F] [Min] | 36 °F |
| Outlet connection size (metric) | M42 |
| Outlet connection standard | Metric |
| Outlet connection type | Thread |
| Outlet pressure [barg] [Max] | 80 barg |
| Outlet pressure [barg] [Min] | 20 barg |
| Outlet pressure [psig] [Max] | 1160 psig |
| Outlet pressure [psig] [Min] | 290 psig |
| Outside dimensions of packaging LxWxH [in] | 14,9x11,8x11,8 |
| Outside dimensions of packaging LxWxH [mm] | 380x300x300 |
| Product group | Pump |
| Product name | APP pumps |
| Seal Material | NBR |
| Serviceable | Yes |
| Sound pressure level [dB(A)] | 78 dBA |
| Speed continuous[rpm] [Min] | 700 rpm |
| Speed [rpm] [Max] | 1800 rpm |
| Speed [rpm] [Min] | 700 rpm |
| Type | APP 5.1-10.2 |
| Type designation | APP 5.1 Ex |
