Description
Flow [gpm] [Max]: 203.000, Flow [l/min] [Max]: 780.780, Outlet pressure [barg] [Max]: 70, Speed [rpm] [Max]: 1780, Speed [rpm] [Min]: 700, Body material: Duplex
Product details
| Gross weight | 123 kg |
| Net weight | 105 kg |
| Gross weight | 123 kg |
| Net weight | 105 kg |
| Ambient temperature [°C] [Max] | 50 °C |
| Ambient temperature [°C] [Min] | 0 °C |
| Ambient temperature [°F] [Max] | 122 °F |
| Ambient temperature [°F] [Min] | 32 °F |
| Body material | Duplex |
| Country of origin | Denmark |
| Description | Pump for sea- or brackish water |
| Displacement [cm³/rev] | 444 cm3/rev |
| Displacement [in³/rev] | 27.09 in3/rev |
| Drain connection size [in] | 1/4 in |
| Drain connection standard | BSPP |
| Drain connection type | Thread |
| Flow [gpm] [Max] | 203 gal/min |
| Flow [gpm] [Min] | 78.62 gal/min |
| Flow [l/min] [Max] | 780.78 L/min |
| Flow [l/min] [Min] | 302.39 L/min |
| Flow [m³/h] [Max] | 47 m3/h |
| Flow [m³/h] [Min] | 18.14 m3/h |
| Inlet connection size (metric) | M60 |
| Inlet connection standard | Metric |
| Inlet connection type | Thread |
| Inlet pressure [barg] [Max] | 5 barg |
| Inlet pressure [barg] [Min] | 2.5 barg |
| Inlet pressure [psig] [Max] | 72.5 psig |
| Inlet pressure [psig] [Min] | 36.5 psig |
| Inlet pressure peak [barg] [Max] | 10 barg |
| Inlet pressure peak [psig] [Max] | 145 psig |
| Media temperature [°C] [Max] | 50 °C |
| Media temperature [°C] [Min] | 2 °C |
| Media temperature [°F] [Max] | 122 °F |
| Media temperature [°F] [Min] | 36 °F |
| Outlet connection size (metric) | M60 |
| Outlet connection standard | Metric |
| Outlet connection type | Thread |
| Outlet pressure [barg] [Max] | 70 barg |
| Outlet pressure [barg] [Min] | 10 barg |
| Outlet pressure [psig] [Max] | 1015 psig |
| Outlet pressure [psig] [Min] | 145 psig |
| Outside dimensions of packaging LxWxH [in] | 22x13,2x18,3 |
| Outside dimensions of packaging LxWxH [mm] | 562x336x466 |
| Product group | Pump |
| Product name | APP pumps |
| Seal Material | NBR |
| Serviceable | Yes |
| Sound pressure level [dB(A)] | 853 dBA |
| Speed continuous[rpm] [Min] | 700 rpm |
| Speed [rpm] [Max] | 1780 rpm |
| Speed [rpm] [Min] | 700 rpm |
| Type | APP 38-46 |
| Type designation | APP 46/1780 |
| Ambient temperature [°C] [Max] | 50 °C |
| Ambient temperature [°C] [Min] | 0 °C |
| Ambient temperature [°F] [Max] | 122 °F |
| Ambient temperature [°F] [Min] | 32 °F |
| Body material | Duplex |
| Country of origin | Denmark |
| Description | Pump for sea- or brackish water |
| Displacement [cm³/rev] | 444 cm3/rev |
| Displacement [in³/rev] | 27.09 in3/rev |
| Drain connection size [in] | 1/4 in |
| Drain connection standard | BSPP |
| Drain connection type | Thread |
| Flow [gpm] [Max] | 203 gal/min |
| Flow [gpm] [Min] | 78.62 gal/min |
| Flow [l/min] [Max] | 780.78 L/min |
| Flow [l/min] [Min] | 302.39 L/min |
| Flow [m³/h] [Max] | 47 m3/h |
| Flow [m³/h] [Min] | 18.14 m3/h |
| Inlet connection size (metric) | M60 |
| Inlet connection standard | Metric |
| Inlet connection type | Thread |
| Inlet pressure [barg] [Max] | 5 barg |
| Inlet pressure [barg] [Min] | 2.5 barg |
| Inlet pressure [psig] [Max] | 72.5 psig |
| Inlet pressure [psig] [Min] | 36.5 psig |
| Inlet pressure peak [barg] [Max] | 10 barg |
| Inlet pressure peak [psig] [Max] | 145 psig |
| Media temperature [°C] [Max] | 50 °C |
| Media temperature [°C] [Min] | 2 °C |
| Media temperature [°F] [Max] | 122 °F |
| Media temperature [°F] [Min] | 36 °F |
| Outlet connection size (metric) | M60 |
| Outlet connection standard | Metric |
| Outlet connection type | Thread |
| Outlet pressure [barg] [Max] | 70 barg |
| Outlet pressure [barg] [Min] | 10 barg |
| Outlet pressure [psig] [Max] | 1015 psig |
| Outlet pressure [psig] [Min] | 145 psig |
| Outside dimensions of packaging LxWxH [in] | 22x13,2x18,3 |
| Outside dimensions of packaging LxWxH [mm] | 562x336x466 |
| Product group | Pump |
| Product name | APP pumps |
| Seal Material | NBR |
| Serviceable | Yes |
| Sound pressure level [dB(A)] | 853 dBA |
| Speed continuous[rpm] [Min] | 700 rpm |
| Speed [rpm] [Max] | 1780 rpm |
| Speed [rpm] [Min] | 700 rpm |
| Type | APP 38-46 |
| Type designation | APP 46/1780 |
