Description
Connection standard: ASME B 36.10M SCHEDULE 80, Connection size [in]: 1 in, Connection type: Butt weld, Electrical connection size: Pg 11, Enclosure rating IP: IP65
Product details
| Gross weight | 11 kg |
| Net weight | 10.1 kg |
| EAN | 5702428242219 |
| Gross weight | 11 kg |
| Net weight | 10.1 kg |
| EAN | 5702428242219 |
| Connection size [in] | 1 in |
| Connection standard | ASME B 36.10M SCHEDULE 80 |
| Connection type | Butt weld |
| Electrical connection size | Pg 11 |
| Electrical connection standard | DIN 43650 |
| Enclosure rating IP | IP65 |
| Max. Working Pressure [bar] | 28 bar |
| Max. Working Pressure [psig] | 406 psig |
| Packing format | Single pack |
| Product description | Float Switch |
| Product group | Switches and thermostats |
| Product name | Liquid level switch |
| Quantity per packing format | 1 pc |
| Refrigerants | R134a R22 R401A R402A R404A R407A R407B R407C R407F R409A R410A R421A R502 R507 R717 |
| Temperature range [°C] [Max] | 65 °C |
| Temperature range [°C] [Min] | -50 °C |
| Temperature range [°F] [Max] | 149 °F |
| Temperature range [°F] [Min] | -58 °F |
| Type | AKS 38 |
| Connection size [in] | 1 in |
| Connection standard | ASME B 36.10M SCHEDULE 80 |
| Connection type | Butt weld |
| Electrical connection size | Pg 11 |
| Electrical connection standard | DIN 43650 |
| Enclosure rating IP | IP65 |
| Max. Working Pressure [bar] | 28 bar |
| Max. Working Pressure [psig] | 406 psig |
| Packing format | Single pack |
| Product description | Float Switch |
| Product group | Switches and thermostats |
| Product name | Liquid level switch |
| Quantity per packing format | 1 pc |
| Refrigerants | R134a R22 R401A R402A R404A R407A R407B R407C R407F R409A R410A R421A R502 R507 R717 |
| Temperature range [°C] [Max] | 65 °C |
| Temperature range [°C] [Min] | -50 °C |
| Temperature range [°F] [Max] | 149 °F |
| Temperature range [°F] [Min] | -58 °F |
| Type | AKS 38 |
