VLT AutomationDrive FC-300
The VLT AutomationDrive represents a single drive concept that controls the entire range of operations from ordinary to servo like applications on any machine or production line. The modular open-technology platform, on which the VLT AutomationDrive is built, makes it exceptionally adaptable and programmable.
Its configurable, user-friendly interface supports local languages and letters.The VLT AutomationDrive series offer an intelligent plug-and-play technology and unmatched reliability making drive operation pure childs play.
Characteristic | Value |
---|---|
Product Group | (FC-) VLT AutomationDrive FC- |
Series | 301 |
Power Rating | (P15K) 15 KW / 20 HP |
Phase | (T) Three phase |
Mains Voltage | (4) 380 - 480 VAC |
Enclosure | (E21) IP21 / Tipo 1 |
RFI Filter | (H1) RFI Class A1/B (C1) |
Brake - Safe Stop | (X) No brake chopper |
LCP | (G) Graphical Loc. Cont. Panel |
Coating PCB | (C) Coated PCB |
Mains Option | (D) Loadsharing |
Adaptation A | (X) Standard Cable Entries |
Adaptation B | (X) No adaptation |
Software Release | (SXXX) Latest release std. SW. |
Software Language Pack | (X) Standard Language Pack |
A Option | (AX) No A Option |
B Option | (BX) No B Option |
C0 Option MCO | (CX) No C0 option |
C1 Option | (X) No C1 option |
C Option Software | (XX) No software option |
D Option | (DX) No D option |
Frame Size | B1 |
Tipocode Part 1 | FC-301P15KT4E21H1XGC |
Tipocode Part 2 | DXXSXXXXAXBXCXXXXDX |
Product Catalog | Global (Standard) |
Vendor | Factory DK |
Vendor Region | Southern Europe |
Calculated Gross Weight | 23.300 |
Calculated Net Weight [kg] | 23.000 |
