Description
Application: Chiller, Function: Evaporator, Max working pressure [psi]: 653, Type designation: C118-EZ, Number of plates: 108, Brazing material: Copper brazing
Product details
| Gross weight | 46 kg |
| Net weight | 39.3 kg |
| EAN | 5702425232213 |
| Gross weight | 46 kg |
| Net weight | 39.3 kg |
| EAN | 5702425232213 |
| Application | Chiller |
| Approval | AS EAC KRAIA PED UA UL |
| Brazing material | Copper brazing |
| Code No. | 111B1835 |
| Design temperature range [°C] [Max] | 200 °C |
| Design temperature range [°C] [Min] | -196 °C |
| Design temperature range [°F] [Max] | 320 °F |
| Design temperature range [°F] [Min] | -390 °F |
| Function | Evaporator |
| Function note | With disteibutor |
| H1 conn. size | 60.3 mm |
| H1 conn. type | Solder connection |
| H2 conn. size | 60.3 mm |
| H2 conn. type | Solder connection |
| Max working pressure [psi] | 653 psi |
| Max. Working Pressure [bar] | 45 bar |
| Model no. | 118 |
| Number of plates | 108 |
| Packing format | Single pack |
| Plate pattern | Z |
| Product group | Heat exchangers |
| Product name | Micro Plate heat exchanger |
| Q3 conn. size range | 5/8 in |
| Q3 conn. type | Solder connection |
| Q4 conn. size range | 1'5/8 in |
| Q4 conn. type | Solder connection |
| Quantity per packing format | 1 pc |
| Refrigerants | R1234ze R134a R22 R290A R32 R404A R407C R407F R410A R444B R452A R513A R600a |
| Type | MPHE C118L-EZ |
| Type designation | C118-EZ |
| Application | Chiller |
| Approval | AS EAC KRAIA PED UA UL |
| Brazing material | Copper brazing |
| Code No. | 111B1835 |
| Design temperature range [°C] [Max] | 200 °C |
| Design temperature range [°C] [Min] | -196 °C |
| Design temperature range [°F] [Max] | 320 °F |
| Design temperature range [°F] [Min] | -390 °F |
| Function | Evaporator |
| Function note | With disteibutor |
| H1 conn. size | 60.3 mm |
| H1 conn. type | Solder connection |
| H2 conn. size | 60.3 mm |
| H2 conn. type | Solder connection |
| Max working pressure [psi] | 653 psi |
| Max. Working Pressure [bar] | 45 bar |
| Model no. | 118 |
| Number of plates | 108 |
| Packing format | Single pack |
| Plate pattern | Z |
| Product group | Heat exchangers |
| Product name | Micro Plate heat exchanger |
| Q3 conn. size range | 5/8 in |
| Q3 conn. type | Solder connection |
| Q4 conn. size range | 1'5/8 in |
| Q4 conn. type | Solder connection |
| Quantity per packing format | 1 pc |
| Refrigerants | R1234ze R134a R22 R290A R32 R404A R407C R407F R410A R444B R452A R513A R600a |
| Type | MPHE C118L-EZ |
| Type designation | C118-EZ |
