084Z8118 Danfoss Temperature sensor, MBT 9110

Write a Review
SKU:
084Z8118
Availability:
2 - 3 weeks

Product details Gross weight 0.67 kg Net weight 0.59 kg EAN 5702423098705 Gross weight 0.67 kg Net weight 0.59 kg…

Adding to cart… The item has been added
Ask for a Quotation

Ask for a Quotation

Feel free to inquire
Request a Quote
  • Security Image 1
Description

Product details

Gross weight 0.67 kg
Net weight 0.59 kg
EAN 5702423098705
Gross weight 0.67 kg
Net weight 0.59 kg
EAN 5702423098705



Ambient temperature max. [°C] 85 °C
Ambient temperature max. [°F] 185 °F
Electrical connection Output 2 wire
Electrical connection size 2 terminals
Enclosure rating IP IP54
Insertion type Fixed
Number of terminals [pcs] 2 pc
Output signal [mA] [Max] 20 mA
Output signal [mA] [Min] 4 mA
Packing format Multi pack
Product group Sensors
Product name Temperature sensor
Quantity per packing format 8 pc
Sensor elem. resistance [Ohm] 100 Ohm
Sensor element [pc] 1 pc
Sensor element type Pt
Supply voltage [V] DC [Max] 35 V
Supply voltage [V] DC [Min] 8 V
Temperature range [°C] [Max] 850 °C
Temperature range [°C] [Min] -200 °C
Temperature range [°F] [Max] 1562 °F
Temperature range [°F] [Min] -328 °F
Transmitter setting range [°C] [Max] 150 °C
Transmitter setting range [°C] [Min] -10 °C
Transmitter setting range [°F] [Max] 302 °F
Transmitter setting range [°F] [Min] 14 °F
Transmitter type Standard in box
Type MBT 9110
Type designation MBT 9110-000B-D215
Wires [pcs] 3 pc
Ambient temperature max. [°C] 85 °C
Ambient temperature max. [°F] 185 °F
Electrical connection Output 2 wire
Electrical connection size 2 terminals
Enclosure rating IP IP54
Insertion type Fixed
Number of terminals [pcs] 2 pc
Output signal [mA] [Max] 20 mA
Output signal [mA] [Min] 4 mA
Packing format Multi pack
Product group Sensors
Product name Temperature sensor
Quantity per packing format 8 pc
Sensor elem. resistance [Ohm] 100 Ohm
Sensor element [pc] 1 pc
Sensor element type Pt
Supply voltage [V] DC [Max] 35 V
Supply voltage [V] DC [Min] 8 V
Temperature range [°C] [Max] 850 °C
Temperature range [°C] [Min] -200 °C
Temperature range [°F] [Max] 1562 °F
Temperature range [°F] [Min] -328 °F
Transmitter setting range [°C] [Max] 150 °C
Transmitter setting range [°C] [Min] -10 °C
Transmitter setting range [°F] [Max] 302 °F
Transmitter setting range [°F] [Min] 14 °F
Transmitter type Standard in box
Type MBT 9110
Type designation MBT 9110-000B-D215
Wires [pcs] 3 pc
Temperature range [°C] [Min]: -200, Temperature range [°C] [Max]: 850, Output signal [mA] [Min]: 4, Output signal [mA] [Max]: 20, Sensor element type: Pt, Sensor elem. resistance [Ohm]: 100, Electrical connection: Output 2 wire, Electrical connection size: 2 terminals
