MCX08M Elect.Control 230V RS485 I/24 More detailsMCX08B has a max. of 8 analogue inputs and 8 digital inputs, a max. of 4 analogue outputs and 8 digital outputs.
| Type Code | MCX08M |
| Weight | 0.363 Kg |
| Analog inputs (AI) | 8 pc |
| Analog outputs (AO) | 4 pc |
| Approval | CE, GOST R, UL |
| Buzzer | Yes |
| Communic. | CANBUS |
| Communic. | MODBUS |
| Communic. | RS485 |
| Connector kit | 080G0180 |
| Connector kit incl. | No |
| Digital inputs (DI) | 8 pc |
| Digital outputs (DO) | 8 pc |
| EAN no. | 5702423285266 |
| Encl. | IP40 |
| Freq. | 50/60 HZ |
| Function | Programmable Controller |
| Identical prod. | 080G0035 |
| Mounting | DIN RAIL |
| Power consumpt. | 10,0 W |
| Prod. Group | Programmable controllers |
| Prod. name | Program. controller, 8 relays |
| Real time clock | Yes |
| Supply volt. AC | 110 - 230 V |
| Type design. | MCX08M4500551 |
