Description
Refrigerants: R134a;R22;R23;R404A;R407A;R407C;R407F;R407H;R410A;R422B;R422D;R438A;R448A;R449A;R449B;R450A;R452A;R463A;R507;R513A;R513B;R515A;R515B;R744, Inlet connection type: SOLDER, ODF, Outlet connection type: SOLDER, ODF
Product details
| Gross weight | 0.33 kg |
| Net weight | 0.29 kg |
| EAN | 5702428329408 |
| Gross weight | 0.33 kg |
| Net weight | 0.29 kg |
| EAN | 5702428329408 |
| Actuator system [mm] | 13.5 mm |
| Ambient temperature | -50 - 50 °C |
| Ambient temperature range [°F] [Max] | 120 °F |
| Ambient temperature range [°F] [Min] | -58 °F |
| Approval | EAC LLC CDC TYSK |
| Coil | No |
| Cv value [gal/min] | 0.18 gal/min |
| Direction | Angleway |
| Function | NC |
| Inlet connection type | SOLDER, ODF |
| Inlet size [in] | 1/2 IN |
| Kv value [m³/h] | 0.162 m3/h |
| Manual operation option | No |
| Max. Working Pressure [bar] | 28 bar |
| Max. Working Pressure [psig] | 400 psig |
| MaxOPD[bar] 10W AC | 18 bar |
| MaxOPD[psi] 10W AC | 260 psi |
| Medium temperature range [°C] [Max] | 60 °C |
| Medium temperature range [°C] [Min] | -50 °C |
| Medium temperature range [°F] [Max] | 140 °F |
| Medium temperature range [°F] [Min] | -58 °F |
| MinODP [bar] | 0 bar |
| MinODP [psi] | 0 psi |
| MOPD[bar/psi] | 18 BAR |
| Orifice size [mm] | 2.3 mm |
| Outlet connection type | SOLDER, ODF |
| Outlet size [in] | 5/8 IN |
| Packing format | Industrial pack |
| Product family name | AKVO |
| Product group | Expansion valves |
| Product name | Electric expansion valve |
| Quantity per packing format | 16 pc |
| Rated capacity R22 [kW] | 16 kW |
| Refrigerants | R407F R422B R422D R448A R449A R449B R450A R452A R513A R407H R438A R463A R513B R515A R515B R134a R22 R23 R404A R407A R407C R410A R507 R744 |
| Type | AKVO 10-7 |
| Type designation | Electric expansion valve |
| Actuator system [mm] | 13.5 mm |
| Ambient temperature | -50 - 50 °C |
| Ambient temperature range [°F] [Max] | 120 °F |
| Ambient temperature range [°F] [Min] | -58 °F |
| Approval | EAC LLC CDC TYSK |
| Coil | No |
| Cv value [gal/min] | 0.18 gal/min |
| Direction | Angleway |
| Function | NC |
| Inlet connection type | SOLDER, ODF |
| Inlet size [in] | 1/2 IN |
| Kv value [m³/h] | 0.162 m3/h |
| Manual operation option | No |
| Max. Working Pressure [bar] | 28 bar |
| Max. Working Pressure [psig] | 400 psig |
| MaxOPD[bar] 10W AC | 18 bar |
| MaxOPD[psi] 10W AC | 260 psi |
| Medium temperature range [°C] [Max] | 60 °C |
| Medium temperature range [°C] [Min] | -50 °C |
| Medium temperature range [°F] [Max] | 140 °F |
| Medium temperature range [°F] [Min] | -58 °F |
| MinODP [bar] | 0 bar |
| MinODP [psi] | 0 psi |
| MOPD[bar/psi] | 18 BAR |
| Orifice size [mm] | 2.3 mm |
| Outlet connection type | SOLDER, ODF |
| Outlet size [in] | 5/8 IN |
| Packing format | Industrial pack |
| Product family name | AKVO |
| Product group | Expansion valves |
| Product name | Electric expansion valve |
| Quantity per packing format | 16 pc |
| Rated capacity R22 [kW] | 16 kW |
| Refrigerants | R407F R422B R422D R448A R449A R449B R450A R452A R513A R407H R438A R463A R513B R515A R515B R134a R22 R23 R404A R407A R407C R410A R507 R744 |
| Type | AKVO 10-7 |
| Type designation | Electric expansion valve |
