Description
Product name: Isolation Valve, Type: MBV 2000
Product details
| Gross weight | 0.12 kg |
| Net weight | 0.1 kg |
| EAN | 5702423133185 |
| Gross weight | 0.12 kg |
| Net weight | 0.1 kg |
| EAN | 5702423133185 |
| Ambient temperature range [°C] [Max] | 200 °C |
| Ambient temperature range [°C] [Min] | -20 °C |
| Ambient temperature range [°F] [Max] | 382 °F |
| Ambient temperature range [°F] [Min] | -4 °F |
| Burst pressure [bar] | 1500 bar |
| External conn. Male/Female | Male |
| External connection size | 1/2 |
| External connection standard | DIN 3852-E |
| External connection type | G |
| Internal connection size | 1/2 |
| Internal connection standard | DIN 3852 |
| Internal connection type | G |
| Max. test pressure [psig] | 8702 psig |
| Max. Working Pressure [bar] | 600 bar |
| Operating temperature [°C] [Max] | 200 °C |
| Operating temperature [°C] [Min] | -20 °C |
| Operating temperature [°F] [Max] | 382 °F |
| Operating temperature [°F] [Min] | -4 °F |
| Packing format | Multi pack |
| Product description | Isolation Valve |
| Product group | Shut-off and regulating valves |
| Product name | Isolation valve |
| Quantity per packing format | 60 pc |
| Specification key | MBV2000-223 |
| Type | MBV 2000 |
| Width across flats [mm] | 30 mm |
| Ambient temperature range [°C] [Max] | 200 °C |
| Ambient temperature range [°C] [Min] | -20 °C |
| Ambient temperature range [°F] [Max] | 382 °F |
| Ambient temperature range [°F] [Min] | -4 °F |
| Burst pressure [bar] | 1500 bar |
| External conn. Male/Female | Male |
| External connection size | 1/2 |
| External connection standard | DIN 3852-E |
| External connection type | G |
| Internal connection size | 1/2 |
| Internal connection standard | DIN 3852 |
| Internal connection type | G |
| Max. test pressure [psig] | 8702 psig |
| Max. Working Pressure [bar] | 600 bar |
| Operating temperature [°C] [Max] | 200 °C |
| Operating temperature [°C] [Min] | -20 °C |
| Operating temperature [°F] [Max] | 382 °F |
| Operating temperature [°F] [Min] | -4 °F |
| Packing format | Multi pack |
| Product description | Isolation Valve |
| Product group | Shut-off and regulating valves |
| Product name | Isolation valve |
| Quantity per packing format | 60 pc |
| Specification key | MBV2000-223 |
| Type | MBV 2000 |
| Width across flats [mm] | 30 mm |
