EVR 25 Valve ODF-ODF 28mm Singlep. More detailsRefrigerants: R22/R407C, R404A/R507, R410A, R134a, R407A, R23. For other refrigerants, please contact Danfoss. Temperature of medium: –40 - +105°C (10 W / 12 W coil). Max. 130°C during defrosting. Min. opening differential pressure, EVR 2-3: 0.0 bar, EVR 6-22: 0.05 bar, EVR 25-32: 0.20 bar.
| Type Code | EVR 25 |
| Weight | 2.63 Kg |
| Actuator system | 13,5 mm |
| Ambient temp. | -40 - 80 °C |
| Ambient temp. range | -40 - 175 °F |
| Approval | EAC, LLC CDC TYSK |
| Coil | No |
| Cv value | 11,600 gpm US |
| Direction | Straightway |
| EAN no. | 5702422067139 |
| Function | N C |
| Inlet type | SOLDER, ODF |
| Inlet size | 28,00 mm |
| Kv value | 10,000 m3/h |
| Man. Operat. | No |
| MWP | 32,0 bar |
| MWP | 460 psig |
| Max. OPD, 10W AC | 21 bar |
| Max. OPD, 20W DC | 14 bar |
| Medium temp. | -40 - 105 °C |
| Medium temp. | -40 - 221 °F |
| Min. ODP | 0,200 bar |
| Orifice size | 25,00 mm |
| Outlet type | SOLDER, ODF |
| Outlet size | 28,00 mm |
| Prod. Group | Solenoid valves |
| Prod. name | Solenoid valve |
| Refrigerant | R134a |
| Refrigerant | R22/R407C |
| Refrigerant | R23 |
| Refrigerant | R404A/R507 |
| Refrigerant | R407A |
| Refrigerant | R410A |
| Type design. | Solenoid valve, Solder |
