027H7202 Danfoss Electric regulating valve, CCMT 8

Write a Review
SKU:
027H7202
Availability:
2 - 3 weeks

Product details Gross weight 1.89 kg Net weight 1.5 kg EAN 5702428453356 Gross weight 1.89 kg Net weight 1.5 kg …

Adding to cart… The item has been added
Ask for a Quotation

Ask for a Quotation

Feel free to inquire
Request a Quote
  • Security Image 1
Description

Product details

Gross weight 1.89 kg
Net weight 1.5 kg
EAN 5702428453356
Gross weight 1.89 kg
Net weight 1.5 kg
EAN 5702428453356



Ambient temperature range [°C] [Max] 60 °C
Ambient temperature range [°C] [Min] -40 °C
Ambient temperature range [°F] [Max] 140 °F
Ambient temperature range [°F] [Min] -40 °F
Approval UL
Connection Solder size [in] 5/8 in
Connection standard EN10220
Connection Weld size [in] 1/2 in
Cv value [gal/min] 0.928 gal/min
Diff.press.setting range [bar] 90 bar
Diff.press.setting range [psi] 1305 psi
Further information Solder, ODF
Kv value [m³/h] 0.928 m3/h
Max. Working Pressure [bar] 140 bar
Max. Working Pressure [psig] 2030 psig
MaxOPD [bar] 90 bar
MaxOPD [psig] 1305 psig
Packing format Single pack
Product description Electric Expansion Valve
Product family name CCMT
Product group Press. and temp. regul. valves
Product name Electric regulating valve
Quantity per packing format 1 pc
Refrigerants R134a
R744
Temperature range [°C] [Max] 60 °C
Temperature range [°C] [Min] -40 °C
Temperature range [°F] [Max] 140 °F
Temperature range [°F] [Min] -40 °F
Type CCMT 8
Ambient temperature range [°C] [Max] 60 °C
Ambient temperature range [°C] [Min] -40 °C
Ambient temperature range [°F] [Max] 140 °F
Ambient temperature range [°F] [Min] -40 °F
Approval UL
Connection Solder size [in] 5/8 in
Connection standard EN10220
Connection Weld size [in] 1/2 in
Cv value [gal/min] 0.928 gal/min
Diff.press.setting range [bar] 90 bar
Diff.press.setting range [psi] 1305 psi
Further information Solder, ODF
Kv value [m³/h] 0.928 m3/h
Max. Working Pressure [bar] 140 bar
Max. Working Pressure [psig] 2030 psig
MaxOPD [bar] 90 bar
MaxOPD [psig] 1305 psig
Packing format Single pack
Product description Electric Expansion Valve
Product family name CCMT
Product group Press. and temp. regul. valves
Product name Electric regulating valve
Quantity per packing format 1 pc
Refrigerants R134a
R744
Temperature range [°C] [Max] 60 °C
Temperature range [°C] [Min] -40 °C
Temperature range [°F] [Max] 140 °F
Temperature range [°F] [Min] -40 °F
Type CCMT 8
Product name: Electric regulating valve, Type: CCMT 8, Refrigerants: R134a;R744, Further information: Solder, ODF

Product details

Gross weight 1.89 kg
Net weight 1.5 kg
EAN 5702428453356
Gross weight 1.89 kg
Net weight 1.5 kg
EAN 5702428453356



Ambient temperature range [°C] [Max] 60 °C
Ambient temperature range [°C] [Min] -40 °C
Ambient temperature range [°F] [Max] 140 °F
Ambient temperature range [°F] [Min] -40 °F
Approval UL
Connection Solder size [in] 5/8 in
Connection standard EN10220
Connection Weld size [in] 1/2 in
Cv value [gal/min] 0.928 gal/min
Diff.press.setting range [bar] 90 bar
Diff.press.setting range [psi] 1305 psi
Further information Solder, ODF
Kv value [m³/h] 0.928 m3/h
Max. Working Pressure [bar] 140 bar
Max. Working Pressure [psig] 2030 psig
MaxOPD [bar] 90 bar
MaxOPD [psig] 1305 psig
Packing format Single pack
Product description Electric Expansion Valve
Product family name CCMT
Product group Press. and temp. regul. valves
Product name Electric regulating valve
Quantity per packing format 1 pc
Refrigerants R134a
R744
Temperature range [°C] [Max] 60 °C
Temperature range [°C] [Min] -40 °C
Temperature range [°F] [Max] 140 °F
Temperature range [°F] [Min] -40 °F
Type CCMT 8
Ambient temperature range [°C] [Max] 60 °C
Ambient temperature range [°C] [Min] -40 °C
Ambient temperature range [°F] [Max] 140 °F
Ambient temperature range [°F] [Min] -40 °F
Approval UL
Connection Solder size [in] 5/8 in
Connection standard EN10220
Connection Weld size [in] 1/2 in
Cv value [gal/min] 0.928 gal/min
Diff.press.setting range [bar] 90 bar
Diff.press.setting range [psi] 1305 psi
Further information Solder, ODF
Kv value [m³/h] 0.928 m3/h
Max. Working Pressure [bar] 140 bar
Max. Working Pressure [psig] 2030 psig
MaxOPD [bar] 90 bar
MaxOPD [psig] 1305 psig
Packing format Single pack
Product description Electric Expansion Valve
Product family name CCMT
Product group Press. and temp. regul. valves
Product name Electric regulating valve
Quantity per packing format 1 pc
Refrigerants R134a
R744
Temperature range [°C] [Max] 60 °C
Temperature range [°C] [Min] -40 °C
Temperature range [°F] [Max] 140 °F
Temperature range [°F] [Min] -40 °F
Type CCMT 8
×
