Description
Product name: Motor operated valve, Type: ICMTS 20 A33, Refrigerants: R744, Inlet connection size [mm]: 25.0, Inlet connection type: Butt weld, Outlet connection size [mm]: 25.0, Outlet connection type: Butt weld
Product details
| Gross weight | 2.43 kg |
| Net weight | 0 kg |
| EAN | 5702428237222 |
| Gross weight | 2.43 kg |
| Net weight | 0 kg |
| EAN | 5702428237222 |
| Application area | Transcritical CO2 systems |
| Body material | Steel |
| Category | Art. 3, par. 3 |
| Compatible Danfoss controllers | EKC 326A |
| Connection material | Steel |
| Connection standard | EN 10220 |
| Cv value [gal/min] | 0.23 gal/min |
| Direction | Straightway |
| Flow direction indicator | Embossed 1-way arrow |
| Fluid Group | I |
| Inlet connection size [in] | 1 in |
| Inlet connection size [mm] | 25 mm |
| Inlet connection type | Butt weld |
| Kv value [m³/h] | 0.2 m3/h |
| Manual operation option | Via ICAD setting Via Multifunction tool |
| Max. Working Pressure [bar] | 140 bar |
| Max. Working Pressure [psig] | 2030 psig |
| MaxOPD [bar] | 90 bar |
| MaxOPD [psig] | 1305 psig |
| Open/close time [s] | 3 ' |
| Outlet connection size [in] | 1 in |
| Outlet connection size [mm] | 25 mm |
| Outlet connection type | Butt weld |
| Packing format | Single pack |
| Parts Program name | ICMTS |
| Product accessories | ICAD accessories ICM / ICS / ICLX accessories |
| Product description | High press. exp. motor valve |
| Product group | Expansion valves |
| Product name | Motor operated valve |
| Quantity per packing format | 1 pc |
| Refrigerants | R744 |
| Serviceable | ICMTS spare parts |
| Temperature range [°C] [Max] | 120 °C |
| Temperature range [°C] [Min] | -60 °C |
| Temperature range [°F] [Max] | 248 °F |
| Temperature range [°F] [Min] | -76 °F |
| Type | ICMTS 20 A33 |
| Valve operation | DIRECT |
| Application area | Transcritical CO2 systems |
| Body material | Steel |
| Category | Art. 3, par. 3 |
| Compatible Danfoss controllers | EKC 326A |
| Connection material | Steel |
| Connection standard | EN 10220 |
| Cv value [gal/min] | 0.23 gal/min |
| Direction | Straightway |
| Flow direction indicator | Embossed 1-way arrow |
| Fluid Group | I |
| Inlet connection size [in] | 1 in |
| Inlet connection size [mm] | 25 mm |
| Inlet connection type | Butt weld |
| Kv value [m³/h] | 0.2 m3/h |
| Manual operation option | Via ICAD setting Via Multifunction tool |
| Max. Working Pressure [bar] | 140 bar |
| Max. Working Pressure [psig] | 2030 psig |
| MaxOPD [bar] | 90 bar |
| MaxOPD [psig] | 1305 psig |
| Open/close time [s] | 3 ' |
| Outlet connection size [in] | 1 in |
| Outlet connection size [mm] | 25 mm |
| Outlet connection type | Butt weld |
| Packing format | Single pack |
| Parts Program name | ICMTS |
| Product accessories | ICAD accessories ICM / ICS / ICLX accessories |
| Product description | High press. exp. motor valve |
| Product group | Expansion valves |
| Product name | Motor operated valve |
| Quantity per packing format | 1 pc |
| Refrigerants | R744 |
| Serviceable | ICMTS spare parts |
| Temperature range [°C] [Max] | 120 °C |
| Temperature range [°C] [Min] | -60 °C |
| Temperature range [°F] [Max] | 248 °F |
| Temperature range [°F] [Min] | -76 °F |
| Type | ICMTS 20 A33 |
| Valve operation | DIRECT |
