COIL 24V 60HZ 20W w. box +P More detailsAmbient temperature: -40 - +50°C. Permissible voltage variation: +10 - -15%. 3-core cable: The external thread in the screwed cable entry suits flexible steel hose or corresponding cable protection. Terminal box: Leads are connected to terminal screws in the terminal box. The box is fitted with a Pg 13.5 screwed entry for 6-14 mm cable. Max lead cross section: 2.5 mm2.
| Type Code | BN024BS |
| Weight | 0.576 Kg |
| Actuator size | 13.5 mm |
| Ambient temp. range | -40 - 50 °C |
| Ambient temp. range | -40 - 120 °F |
| Approval | LLC CDC TYSK |
| Coil conn. | CONNECTION BOX |
| Colour | Blue |
| EAN no. | 5702428026383 |
| Encl. | IP67 |
| Freq. | 60 HZ |
| Identical prod. | 018F8902 |
| Power consumpt. | 20,0 W |
| Prod. Group | Solenoid valves |
| Prod. name | Solenoid coil |
| Spare part no. | 018F6902 |
| Supply volt. AC | 24 V |
| Type design. | BN024BS |
